Stainless Steel Materials Flip Weighing Bucket Sashimi 7 -Head 120
Flip Type Weigher For Fresh Aquatic Industry
Application:
This product is suitable for the fresh and aquatic industry. The
single material is large in volume, large in shape and irregular in
shape, such as squid, fur belly, sashimi and other sticky
materials.
Functional Performance:
——High speed, high precision:Adopt high-precision digital sensor,
fast sampling speed and high precision.
——Zero tracking:Can be reset manually or automatically, and dynamic
zero tracking.
——Weighing accuracy:The latest optimized sampling algorithm to
improve weighing accuracy.
——Material blocking problem : Multiple feeding hopper discharges
can effectively solve blockage.
——Precise localization :Intelligent fault detection and error
reporting, accurate positioning to solve problems.
——Accurate counting:The combination of weighing and counting
functions improves counting accuracy.
Overall Dimension:
Action Performance:
Each weighing hopper corresponds to two memory buckets in the lower
layer. After taking the value, turn left and right to put the
material into the corresponding memory bucket respectively. A total
of 14 memory buckets in the lower layer participate in combining
the target weight value. The combined material is put into the
lower aggregate conveying line and transported to the subsequent
station.
1. Flip weighing bucket, no bucket door structure, avoid material
clamping.
2. The weighing unit is distributed in a single row, which is easy
to operate and is equipped with an automatic feeding device.
3. The corrugated structure of the material contact surface reduces
the friction force of the contact surface and prevents the material
from sticking and remaining.
Specifications:
| Model | TY-ZHZ072M120-01-12 |
| Power Supply | AC220V±10% 50Hz (60HZ) |
| Rated power | 1kW |
| Max.Weighing (one hopper) | 50~1000g |
| Accuracy | ±0.5g |
| Min.Scale Interval | 0.1g |
| Weighing speed | 20~30 BPM |
| Weighing material size | ≤180mm(L)*50mm(W)*50mm(H) |
| Product dimensions | 2000mm(L)*900mm(W)*1200mm(H) |
| Control system | MCU |
| Preset Product Number | 99 |
| Operating Direction | Face the machine, from right to left |
